خدمة إعادة تشكيل أعمدة الكامات لمحرك 2.0 TFSI EA113

What is camshaft reprofiling? How are camshafts upgraded?

 Reprofiling is an improvement of camshafts in terms of valve opening duration and lift, filling the cylinder with more air, resulting in greater power output, especially at high RPMs. The upgrade is done by removing material on regrinding machines, reshaping each cam lobe. The new lobe we achieve is larger when measured with a protractor over a full Otto cycle. By installing larger camshafts and positioning them correctly, we can achieve higher horsepower at high RPMs with the same pressure compared to stock camshafts. For proper operation of the hydraulic lifters, due to material removal on the lobes at higher stages, shim spacers are provided to ensure smooth idling and cold starts.

المرحلة 2: رفع الصمامات سحب/عادم: 11 / 10.8

المرحلة 3: رفع الصمامات سحب/عادم: 11.4 / 10.5

المرحلة 2: مدة فتح الصمامات سحب/عادم: 256 / 264

المرحلة 3: مدة السحب/العادم: 264 / 270

For the upgrade to function properly, it is essential to replace the valve springs to prevent valve bounce under turbo pressure and at high RPMs

Welcome to our team!

انتباه: يجب أن تكون أعمدة الكامات التي سترسلها لنا من محرك يعمل بشكل سليم.
